BTMC-1-D16-003LE

£225.50 + VAT (£270.60 inc. VAT)

Pack of 10, bolt gauges for use with CN, 1mm gauge length, with 30mm leadwires

2 in stock

SKU: BTMC-1-D16-003LE Category:

Description

Pack of 10, bolt gauges for use with CN, 1mm gauge length, with 30mm leadwires

These gauges are used for measurement of tensile strain of bolt. They are simply inserted into a pre-drilled hole in the bolt head together with exclusive adhesives. This method is recommendable when an ordinary strain gauge cannot be mounted on the bolt surface. Accurate tensile force measurement is possible by calibrating the bolt after installing the bolt gauges.

Resistance 120Ω
Applicable specimen Bolt M10 or larger
Backing Special plastics
Operational temp. (°C) -10~+80°C
Element Cu-Ni
Strain Limit 0.5%(5000×10-6strain)
Bonding adhesive CN
